ISO 1403
Water Hose
ISO 1403
Water Delivery Hose
SKU: WAT-DEL-001 · 6 sizes available
General-purpose water delivery hose for water transfer and discharge.
$0.70 /meter
From $0.70/m
MOQ 100m
| Quantity (meters) | Unit Price | |
|---|---|---|
| 100–299 m | $1.01/m | |
| 300–999 m | $0.90/m | |
| 1,000–4,999 m | $0.78/m | |
| 5,000+ m | $0.70/m | Best |
Working pressure: 1 MPa / 150 PSI
Burst pressure: 3 MPa / 435 PSI
Temperature: -10°C to +80°C
Inner diameter: 13 mm – 50 mm
Reinforcement: High-tensile textile yarn braid
Product description
General-purpose water delivery hose for water transfer and discharge. Standard: ISO 1403. Working pressure: 1 MPa / 150 PSI. Application: general water delivery and discharge.
Technical specifications
| Standard | ISO 1403 |
|---|---|
| Application | general water delivery and discharge |
| Construction | Water-resistant EPDM/synthetic rubber tube, high-tensile textile reinforcement, weather-resistant cover |
| Working pressure | 1 MPa / 150 PSI |
| Burst pressure | 3 MPa / 435 PSI |
| Temperature range | -10°C to +80°C |
| Inner diameter | 13 mm – 50 mm |
| Outer diameter | 20 mm – 60 mm |
| Reinforcement | High-tensile textile yarn braid |
| Cover material | EPDM/synthetic rubber, weather resistant |
| Roll length | 50 m / 100 m |
| Packaging | Wrapped in plastic film, on wooden reel |
| Certification | ISO 9001, CE |
Suitable applications
