EN 853 1SN (oil)
Oil & Fuel Hose
EN 1360
Fuel Dispenser Hose
SKU: OIL-FDP-001 · 5 sizes available
Fuel dispenser hose for petrol-station pumps and fuel delivery.
$1.15 /meter
From $1.15/m
MOQ 100m
| Quantity (meters) | Unit Price | |
|---|---|---|
| 100–299 m | $1.67/m | |
| 300–999 m | $1.47/m | |
| 1,000–4,999 m | $1.29/m | |
| 5,000+ m | $1.15/m | Best |
Working pressure: 1.6 MPa / 232 PSI
Burst pressure: 4.8 MPa / 696 PSI
Temperature: -40°C to +100°C
Inner diameter: 6.3 mm – 25 mm
Reinforcement: High-tensile steel wire / textile braid
Product description
Fuel dispenser hose for petrol-station pumps and fuel delivery. Standard: EN 1360. Working pressure: 1.6 MPa / 232 PSI. Application: petrol station fuel dispensing.
Technical specifications
| Standard | EN 1360 |
|---|---|
| Application | petrol station fuel dispensing |
| Construction | Oil- and fuel-resistant NBR/FKM tube, textile or wire reinforcement, oil-resistant cover |
| Working pressure | 1.6 MPa / 232 PSI |
| Burst pressure | 4.8 MPa / 696 PSI |
| Temperature range | -40°C to +100°C |
| Inner diameter | 6.3 mm – 25 mm |
| Outer diameter | 13 mm – 36 mm |
| Reinforcement | High-tensile steel wire / textile braid |
| Cover material | NBR/synthetic rubber, oil & fuel resistant |
| Roll length | 50 m / 100 m |
| Packaging | Wrapped in plastic film, on wooden reel |
| Certification | ISO 9001, CE, EN 1360 (fuel models) |
