Fuel hose diesel gasoline oil resistant hose oil pipe refueling machine accessories

Product name:Rubber Hose
Material:EPDM, NBR, NR, Silicone
Application:Mainly used for conveyance of diesel, gasoline etc
Color:black/red/blue/ customized
Working temperature:-35℃-+100℃
Thickness:1-10mm/As Customized
Working pressure:0.3Mpa~1.2Mpa
Inner Diameter:2mm~ 135mm or as reguest
Processing Service:Cutting
Keywords:fuel hose

分类:

描述

Product Description

Product Features:

1. Excellent oil resistance: The special rubber formula, such as nitrile rubber, etc., makes it have excellent tolerance to various oils, including gasoline, diesel, lubricating oil, hydraulic oil, etc., effectively preventing the oil pipe from swelling, softening, rupture and other damage due to contact with oil.

2. Good corrosion resistance: In addition to oil resistance, it also has a certain corrosion resistance, which can resist the erosion of impurities and chemicals that may be contained in the oil to the oil pipe, and extend the service life of the oil pipe. High strength and pressure resistance: The internal structure usually adopts a multi-layer structure design, such as a cloth winding layer and a steel wire reinforcement layer, which enhances the strength and pressure resistance of the oil pipe, can withstand high working pressure, ensure the stable transportation of oil, and is not prone to leakage and other problems.

3. Flexibility and fatigue resistance: The rubber material gives the oil pipe good flexibility, so that it can adapt to various complex installation environments and bending requirements. At the same time, it has good fatigue resistance. After multiple bending and stretching, it can still maintain stable performance, reducing damage caused by frequent use.

4. High and low temperature resistance: Some rubber oil-resistant pipes can work normally in a wide temperature range, such as – The temperature range of 40℃ to 120℃ or even higher can meet the use requirements in different seasons and working conditions.

Car fuel hose:


Features:

Fuel Hose Thousands Of Kinds for Your Options.
These silicone hose, silicone reducer hose , hump hose , silicone elbow hose ,silicone heater hose are available in a wide range of size and colors. Custom products are available ! We can do customize according to samples, drawings.

Durable Stable Structure:

Fuel Line is made of inner rubber( air tight nitrile rubber) , Outer rubber (NBR rubber ) ,
Middle reinforcement layer( high-strength polyester fiber) enhance the pressure bearing and working pressure anti-aging performance.

Chemical Stability Features:
Fuel Line Hose it has excellent Anti Hardening, and chemical stability, especially suitable for outdoor , and has good resistance to ultraviolet and ozone.
please contact me to obtain quotes and free samples

Construction:
Tube: Black,smooth,NBR rubber. Reinforcement: High strength synthetic yarn.
Cover: Ozone ,oil resistant synthetic nitrile rubber

Characteristics:
1.Weather and abrasion resistant cover
2.Flexible and less distortion

Product structure:

1. Inner rubber layer :

directly in contact with oil, made of high-quality oil-resistant rubber, with good sealing and oil resistance, can effectively prevent oil penetration.

2. Reinforcement layer :

generally made of multiple layers of cloth, steel wire or fiber, its function is to increase the strength and pressure resistance of the oil pipe, improve the tensile and explosion resistance of the oil pipe. 3. Outer rubber layer :
covers the outside of the reinforcement layer, plays a role in protecting the reinforcement layer and the entire oil pipe, and also has a certain degree of weather resistance and wear resistance, preventing the oil pipe from being affected by external environmental factors

Product materials:

1. Nitrile rubber :

It has excellent oil resistance, wear resistance, heat resistance and aging resistance. It is one of the commonly used materials for manufacturing rubber oil-resistant pipes. It is suitable for the transportation of most oil media. The working temperature range is generally – 30℃ to Around 120℃.
2. Neoprene :
It has good oil resistance, weather resistance, chemical corrosion resistance and flame retardancy. Its oil resistance is second only to nitrile rubber, and it has good tear resistance. It is often used in some occasions with high requirements for oil resistance and weather resistance.
3. Natural rubber :
It has excellent elasticity, flexibility and wear resistance, but relatively poor oil resistance. It generally needs special treatment or is used in combination with other oil-resistant rubbers to improve its oil resistance. It is suitable for some occasions that do not require particularly high oil resistance but have high requirements for flexibility and elasticity.
4. Fluororubber :
It has excellent oil resistance, corrosion resistance, high temperature resistance and aging resistance. It can work stably for a long time in a more severe working environment, but its price is relatively high. It is generally used in special occasions with extremely high requirements for oil resistance and temperature resistance, such as aerospace, high-end chemical industry and other fields

Product Application:

1. Automobile Industry :

As the fuel pipe, oil pipe, oil return pipe, etc. of the automobile, it ensures the normal operation of key components such as the engine and transmission, and provides reliable oil delivery guarantee for the power transmission and lubrication system of the automobile.

2. Engineering Machinery :
Widely used in the hydraulic systems of various types of engineering machinery such as excavators, loaders, cranes, etc., to deliver hydraulic oil, realize various movements and operations of the machinery, and withstand high pressure and frequent oil shock.

3. Petrochemical :
Used for oil delivery in the links of oil extraction, refining, storage and transportation, such as oil pipelines, oil depot connecting pipes, etc., which can adapt to complex chemical environments and high-demand working conditions.

4. Industrial Equipment:
In various industrial production equipment, such as machine tools, injection molding machines, die-casting machines, etc., as lubricating oil pipes, hydraulic oil pipes, etc., provide necessary oil support for the normal operation of the equipment and ensure the accuracy and stability of the equipment.

Company Profile

Contact US

其他信息

Product name

Rubber Hose

Material

EPDM, NBR, NR, Silicone

Application

Mainly used for conveyance of diesel, gasoline etc

Color

black/red/blue/ customized

Working temperature

-35℃~+100℃

Thickness

1-10mm/As Customized

Working pressure

0.3Mpa~1.2Mpa

Inner Diameter

2mm~ 135mm or as reguest

Processing Service

Cutting

Keywords

fuel hose
